| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
100,000 pcs
|
100000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Data Rate | |
| Duplex | |
| ESD Protection | |
| Fault Protection | |
| Mounting Type | |
| Number of Drivers | |
| Operating Temperature | |
| Protocol | |
| Receiver Hysteresis | |
| Supplier Device Package | |
| Supply Current | |
| Type | |
| Voltage |
The SN65ALS1176D is a half-duplex differential transceiver optimized for PROFIBUS applications, meeting TIA/EIA-485-A standards. It operates within a voltage range of 4.75V to 5.25V and supports signaling rates up to 40 Mbps.
This transceiver features a common-mode range of -7V to 12V and provides fault protection within the same range. It is designed to handle up to 160 transceivers on a bus, making it suitable for complex network configurations. The device offers a receiver hysteresis of 60 mV and has a low bus capacitance of 10 pF (Max) to minimize signal distortion.
Packaged in an 8-SOIC (0.154", 3.90mm Width) surface-mount configuration, the SN65ALS1176D operates reliably in industrial environments with an operating temperature range of -40°C to 85°C. It includes features such as ESD protection exceeding ±10 kV HBM and common-mode rejection up to 50 MHz.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.44 | $1.44 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The SN65ALS1176D operates within a voltage range of 4.75 to 5.25 V.
The SN65ALS1176D is packaged in an 8-SOIC surface-mount package.
The maximum signaling rate supported is 40 Mbps.
It supports RS422 and RS485 protocols.
The operating temperature range is from -40°C to 85°C.
It provides fault protection from -7 to 12 V.
It has ESD protection of ±10 kV HBM.
