| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
211 pcs
|
211 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
16 pcs
|
16 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request | |
|
9 pcs
|
9 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Automotive Grade | |
| Capacitance | |
| Dielectric Material | |
| Halogen Free | |
| Height | |
| Lead Style | |
| Length | |
| Mounting Type | |
| Operating Temperature | |
| Ratings | |
| Termination | |
| Tolerance | |
| Voltage Rating | |
| Width |
The KEMET SMP253MA4470MTR24 is a Y2 class EMI suppression capacitor from the SMP253 series. It features a metallized paper dielectric and is designed for line-to-earth applications in electromagnetic interference suppression. This capacitor is rated at 250 VAC and 1500 VDC, with a capacitance of 4700 pF and a tolerance of ±20%. It is automotive grade, complying with AEC-Q200 requirements. The component is surface mountable, with a nonstandard package (size code 5045) measuring 12.70 mm x 11.50 mm x 6.70 mm. It operates over a temperature range of -40°C to 100°C and meets UL94 V-0 flammability standards. The capacitor is RoHS compliant and lead-free. It is supplied in tape and reel packaging (TR24). The part is approved under ENEC and cULus and has a high dv/dt capability. Note: The datasheet indicates this component is obsolete.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.90 | $2.90 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
4700 pF (0.0047 µF).
Rated at 250 VAC (50/60 Hz) and 1500 VDC.
Metallized paper.
±20%.
Surface mount, nonstandard package (size code 5045, dimensions 12.70 mm x 11.50 mm x 6.70 mm).
-40°C to 100°C.
Yes, AEC-Q200 qualified.
