The SMMUN2213LT1G from On Semiconductor is a digital transistor featuring a monolithic bias resistor network, integrating R1 and R2 resistors into a single device. This design simplifies circuit construction and reduces board space.
Key electrical specifications include a maximum collector-emitter voltage (VCEO) of 50Vdc and a continuous collector current (IC) of 100mAdc. The transistor type is NPN with pre-bias, and it includes integrated resistors of 47 kΩ for R1 and R2. The DC current gain (hFE) is a minimum of 80 at 5mA collector current and 10V Vce, with a Vce saturation of 250mV maximum at 300µA base current and 10mA collector current.
This device is housed in a SOT-23-3 (TO-236) surface mount package, suitable for automated assembly processes. It operates with a maximum power dissipation of 246mW at 25°C ambient temperature.
The SMMUN2213LT1G is Pb-Free and Halogen Free, aligning with environmental compliance standards. It is designed to replace single transistors and external bias networks, offering a cost-effective and space-saving solution for various digital applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum collector-emitter voltage (VCEO) for the SMMUN2213LT1G is 50 Vdc.
The continuous collector current (IC) rating for this transistor is 100 mAdc.
The SMMUN2213LT1G is supplied in a SOT-23-3 (TO-236) package, designed for surface mounting.
The SMMUN2213LT1G is listed as RoHS3 Compliant.
The moisture sensitivity level (MSL) is 1.
