| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
32 pcs
|
32 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact System | |
| Contact Type | |
| Current Rating (Amps) | |
| Data Rate (Maximum) | |
| Fastening Type | |
| Halogen Free | |
| Insertion Depth | |
| Insulation Color | |
| Insulation Height | |
| Insulator Material | |
| Lead Spacing | |
| Lead Style | |
| Lead-Free Solderable | |
| Material Flammability Rating | |
| Mating Cycles | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Orientation | |
| Packaging Type | |
| Pitch | |
| Row Spacing | |
| SMT Lead Coplanarity | |
| SVHC Present | |
| Standard Package Quantity | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The Samtec SMM-125-01-S-D is a 50-position, 2-row, 2.00mm pitch board-to-board receptacle connector from the Tiger Eye series. It features a push-pull fastening mechanism and is designed for through-hole solder termination. The connector uses a high-reliability multi-finger beryllium copper contact system with 30 µ" gold plating on the contact area and matte tin on the tail, ensuring excellent conductivity and durability.
Electrical ratings include 3.2A per contact (with 2 pins powered) and a voltage rating of 350VAC. The connector supports data rates up to 8 Gbps, making it suitable for high-speed signal applications. The operating temperature range is -55°C to 125°C, and the insulator is made of black liquid crystal polymer with a UL94 V-0 flammability rating.
The SMM-125-01-S-D is packaged in tubes with a standard quantity of 11 pieces per tube. It mates with Samtec board-mount pin headers such as TMM, TMMH, MTMM, MMT, LTMM, TW, PTT, and ZLTMM, as well as TCMD cable mates. This connector is ideal for board-to-board or cable-to-board interconnects requiring high reliability and compact 2.00mm pitch spacing.
| Qty | Low | High |
|---|---|---|
| 1+ | $11.70 | $11.70 |
| 10+ | $10.81 | $10.81 |
| 25+ | $10.00 | $10.00 |
| 50+ | $9.31 | $9.31 |
| 100+ | $9.25 | $9.25 |
| 500+ | $102.15 | $102.15 |
| 1,000+ | $100.11 | $100.11 |
| 5,000+ | $98.11 | $98.11 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
50 positions, all loaded.
2.00mm (0.079 inches).
3.2A per contact (2 pins powered).
350VAC.
Through hole, solder termination.
-55°C to 125°C.
30 µ" gold on contact, matte tin on tail.
