| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
650 pcs
|
650 pcs | On Request | 1 | On Request | On Request | 643 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish - Mating | |
| Contact Finish - Tail | |
| Contact Finish Thickness | |
| Contact Material | |
| Contact System | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Data Rate | |
| Fastening Type | |
| Halogen Free | |
| Insertion Depth | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Lead-Free Solderable | |
| Material Flammability Rating | |
| Max Mating Cycles | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Orientation | |
| Packaging Type | |
| Pitch | |
| Row Spacing | |
| SMT Lead Coplanarity | |
| Standard Package Quantity | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The Samtec SMM-122-02-S-D is a 44 position, 2 row, 2.00mm pitch surface mount receptacle connector from the SMM Tiger Eye series. It features a black liquid crystal polymer insulator and beryllium copper contacts with 30µ" gold plating on the mating area and matte tin on the tails. The connector is rated for 3.2A per pin (2 pins powered) and 350VAC, with an operating temperature range of -55°C to +125°C.
Designed for board-to-board or cable applications, this vertical receptacle uses a push-pull fastening system and supports data rates up to 8 Gbps. The contact system is the high-reliability Tiger Eye multi-finger design. The connector has an insulation height of 3.56mm and an insertion depth range of 3.05mm to 3.25mm.
The SMM-122-02-S-D is packaged in tubes with 13 parts per package. It is lead-free solderable and has a flammability rating of UL94 V-0. The SMT lead coplanarity is 0.10mm maximum.
| Qty | Low | High |
|---|---|---|
| 1+ | $15.57 | $15.57 |
| 2+ | $98.26 | $98.26 |
| 10+ | $96.30 | $96.30 |
| 20+ | $94.37 | $94.37 |
| 50+ | $92.48 | $92.48 |
| 100+ | $90.64 | $90.64 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
44 positions in 2 rows.
2.00mm (0.079 inches).
3.2A per pin with 2 pins powered.
350 VAC.
Surface mount with solder termination.
-55°C to +125°C.
Beryllium copper with 30µ" gold plating on mating area and matte tin on tail.
