| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
42 pcs
|
42 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Type | |
| Current Rating (Amps) | |
| Data Rate | |
| Fastening Type | |
| Halogen Free | |
| Insertion Depth | |
| Insulation Color | |
| Insulation Height | |
| Insulator Material | |
| Lead Spacing | |
| Lead Style | |
| Lead-Free Solderable | |
| Material Flammability Rating | |
| Max Mating Cycles | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Orientation | |
| Packaging Type | |
| Pitch | |
| Standard Package Quantity | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The SMM-109-01-S-S is a 9-position, single row, female socket receptacle from Samtec's Tiger Eye series. The connector utilizes a 2.00mm (0.079") pitch and is designed for through-hole mounting with solder termination. The contact system is high-reliability beryllium copper with a gold plating on the contact area (30µin) and matte tin on the tail.
Electrical ratings include a current capacity of 3.2A per pin and a voltage rating of 350 VAC. It supports data rates up to 8 Gbps, making it suitable for high-speed board-to-board or cable-to-board applications. The operating temperature range is -55°C to +125°C.
The insulator is a black liquid crystal polymer rated UL94 V-0. The connector is packaged in a tube with 32 parts per package. Mating cycles are rated up to 100 cycles, and the insertion depth is 3.05mm to 3.25mm.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.72 | $3.72 |
| 50+ | $3.03 | $3.03 |
| 100+ | $2.52 | $2.52 |
| 500+ | $2.16 | $2.16 |
| 1,000+ | $2.14 | $2.14 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 9 positions in a single row configuration.
The pitch is 2.00 mm (0.079").
The current rating is 3.2 A per pin (with 2 pins powered).
The voltage rating is 350 VAC.
It is a through-hole connector with solder termination.
The operating temperature range is -55°C to +125°C.
