SMI10-5-K-I38 The CUI Inc. SMI10-5-K-I38 is a 10W AC-DC power supply with a 5V output voltage and a USB Type A receptacle. It features universal input and DoE Level VI efficiency.
Mfr Part #:

SMI10-5-K-I38

Mfr Name: CUI Inc.
CUI Inc.
The CUI Inc. SMI10-5-K-I38 is a 10W AC-DC power supply with a 5V output voltage and a USB Type A receptacle. It features universal input and DoE Level VI efficiency.
Stock on Request

SMI10-5-K-I38 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Approval Agency
Current
Dimensions
Efficiency
Form
Height
Input Connector
Input Frequency
Input Type
Input Voltage
Mounting Type
No Load Power Consumption
Operating Temperature
Output Connector
Output Voltage
Power (Watts)
Region Utilized
Standard Number
Storage Temperature
Voltage
Weight
Width
View Similar Products (0)

SMI10-5-K-I38 Description

Short technical summary and product information.

The CUI Inc. SMI10-5-K-I38 is a versatile AC-DC power supply designed for various applications. It delivers up to 10W of continuous power with a stable 5V output voltage and a maximum output current of 2A.



This power supply boasts a universal input voltage range of 90-264 Vac and a frequency range of 47-63 Hz, making it suitable for global use. It meets DoE Level VI and CoC Tier 2 efficiency standards, with a low no-load power consumption of less than 0.075W.



Key features include over-voltage and short-circuit protections for enhanced safety. The unit is certified to UL/EN/IEC 62368 standards and carries multiple safety approvals including UL/cUL, RCM, CCC, and PSE. The output is provided via a USB Type A receptacle.



Designed for wall mounting, the SMI10-5-K-I38 has compact dimensions of 60.9 x 38 x 29.2 mm. It includes interchangeable AC blades for international compatibility, with options for North America, Europe, UK, Australia, and China.

SMI10-5-K-I38 Quick Information

Product Type: AC-DC Power Supply
Series: SMI10-USB
Canonical Name: CUI Inc. SMI10-5-K-I38 AC-DC Power Supply
Subcategory: Wall Mount Adapter

SMI10-5-K-I38 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

SMI10-5-K-I38 Features

  • 10W continuous power output.
  • 5V output voltage.
  • Universal 90-264 Vac input range.
  • DoE Level VI, CoC Tier 2 efficiency.
  • USB Type A output receptacle.

SMI10-5-K-I38 Applications

  • Suitable for ITE (Commercial) applications.
  • Designed for global use with interchangeable blades.
  • Provides reliable power for electronic devices.
  • Compact wall mount form factor.

SMI10-5-K-I38 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the input voltage range of the SMI10-5-K-I38?

The input voltage range is 90 to 264 Vac at 47 to 63 Hz.

What is the operating temperature range?

The operating temperature range is 0°C to 40°C.

What is the mounting type and package size?

The adapter is wall mount with dimensions 60.9 x 38 x 29.2 mm and weight 40 g without blades.

What are the output voltage and current ratings?

The output is 5 Vdc at up to 2 A, with maximum power of 10 W.

What is the efficiency and no-load power consumption?

Average efficiency is 80.9% (Level VI / CoC Tier 2). Typical no-load power consumption is 0.06 W, maximum 0.075 W.

What safety approvals does the SMI10-5-K-I38 have?

Safety approvals include UL/cUL, RCM, CCC, PSE, UKCA, certified to 62368-1.

What protection features are included?

Over voltage protection (zener clamp at 10 Vdc), over current protection (auto recovery at 4 A), and short circuit protection (auto recovery).
