SMCJ24A The Vishay SMCJ24A is a unidirectional TVS diode designed for ESD protection. It features a 24V working voltage and a 1.5kW peak pulse power dissipation.
Mfr Part #:

SMCJ24A

Available from 2 distributors
Mfr Name: BrightKing
BrightKing
The Vishay SMCJ24A is a unidirectional TVS diode designed for ESD protection. It features a 24V working voltage and a 1.5kW peak pulse power dissipation.
✓ Total Stock: 950,030 pcs

SMCJ24A Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Smaxon Electronics ✓
Non-Authorised Inventory information
950,000 pcs
On Request
950000 pcs On Request 1 On Request On Request 18+ On Request On Request
PROSOFT ELECTRONICS ✓
Non-Authorised Inventory information
30 pcs
On Request
30 pcs On Request 1 On Request On Request 24+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

SMCJ24A Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Package / Case
Storage Temperature
Tape & Reel
Termination Style
Working Voltage
View Similar Products (0)

SMCJ24A Description

Short technical summary and product information.

The Vishay SMCJ24A is a unidirectional Transient Voltage Suppressor (TVS) diode designed for ESD protection applications. It operates with a working voltage of 24V and has a breakdown voltage of 26.7V. The device can handle a peak pulse current of 38.6A and offers a peak pulse power dissipation of 1.5kW.



This TVS diode is suitable for a wide range of operating temperatures, from -55°C to +150°C. It is packaged in a DO-214AB SMD/SMT form factor, supplied on a reel or cut tape, making it ideal for automated assembly processes.



Key electrical characteristics include a clamping voltage of 38.9V. The SMCJ24A is part of the SMCJ_A series, providing robust protection against transient voltage events.

SMCJ24A Quick Information

Product Type: TVS Diode
Series: SMCJ_A
Canonical Name: SMCJ24A Unidirectional TVS Diode
Subcategory: ESD Protection Diodes / TVS Diodes

SMCJ24A Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

SMCJ24A Features

  • Unidirectional TVS diode for ESD protection.
  • 24V working voltage.
  • 1.5kW peak pulse power dissipation.
  • SMD/SMT package for automated assembly.
  • Wide operating temperature range.

SMCJ24A Applications

  • Protects sensitive electronic circuits.
  • Ideal for transient voltage suppression.
  • Suitable for industrial equipment.
  • Used in consumer electronics.
  • Applications requiring ESD protection.

SMCJ24A FAQs

7 frequently asked questions generated from this part’s specifications.
What is the working voltage of the SMCJ24A TVS diode?

The working voltage of the SMCJ24A is 24 V.

What is the breakdown voltage for the SMCJ24A?

The breakdown voltage for the SMCJ24A is 26.7 V.

What is the clamping voltage of the SMCJ24A?

The clamping voltage of the SMCJ24A is 38.9 V.

What is the peak pulse current rating for the SMCJ24A?

The peak pulse current rating for the SMCJ24A is 38.6 A.

What is the peak pulse power dissipation of the SMCJ24A?

The peak pulse power dissipation of the SMCJ24A is 1.5 kW.

What is the operating temperature range for the SMCJ24A?

The operating temperature range for the SMCJ24A is -55°C to +150°C.

What package type is the SMCJ24A supplied in?

The SMCJ24A is supplied in a DO-214AB SMD/SMT package.
