The SolaHD SLS-12-034T is an open frame AC/DC converter designed for ITE (Commercial) applications. It operates within a wide input voltage range of 100 to 240 VAC and provides a single output of 12V at 3.4A, delivering a total of 41W.
Key features include adjustable output and remote sense, enhancing its flexibility in various designs. The converter is designed for chassis mounting and operates within a temperature range of 0°C to 50°C. Its dimensions are 142.7mm in length, 123.7mm in width, and 32.5mm in height.
This AC/DC converter is approved by CSA and cURus, ensuring compliance with relevant safety standards. It is RoHS3 compliant and has an MSL rating of 1.
The SLS-12-034T provides a single output of 12V at 3.4A.
The input voltage range is 100 to 240 VAC.
The power rating is 41W.
It uses chassis mount.
The operating temperature range is 0°C to 50°C.
It has CSA and cURus approvals.
