| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Type | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Prop 65 | |
| SVHC Present | |
| Style | |
| Tape & Reel | |
| Termination |
The SLM-115-01-G-S is a micro low profile receptacle connector from Samtec's SLM series. It has 15 positions arranged in a single row with a 0.050" (1.27mm) pitch. The connector uses through hole mounting with solder termination, making it suitable for board-to-board stacking applications.
The contact material is phosphor bronze with a 20 µ" (0.51 µm) gold plating on the contact area and gold flash on the balance. The insulator is black glass filled polyester. The connector is rated for 5.2 A per pin when 2 pins are powered, and operates over a temperature range of -55°C to 125°C.
This receptacle mates with Samtec HTMS, TMS, MTMS, DWM, HDWM, FTR, and HMTMS headers. The insertion depth is 2.03 mm to 3.05 mm. Packaging is in tubes of 30 pieces. The part is RoHS3 compliant, REACH compliant with no SVHCs, and has a moisture sensitivity level of not moisture sensitive.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.57 | $3.57 |
| 10+ | $2.68 | $2.68 |
| 30+ | $2.58 | $2.58 |
| 1,020+ | $2.03 | $2.03 |
| 2,010+ | $1.89 | $1.89 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
15 positions.
1.27mm (0.050 inches).
5.2 A per pin when 2 pins are powered.
Through hole.
-55°C to 125°C.
20 µ" (0.51 µm) gold on contact, gold flash on balance.
Tube of 30 pieces.
