| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
200 pcs
|
200 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Type | |
| Current Rating | |
| Fastening Type | |
| Halogen Free | |
| Insertion Depth | |
| Insulation Color | |
| Insulation Height | |
| Insulator Material | |
| Lead Free Solderability | |
| Lead Spacing | |
| Lead Style | |
| Mating Connector Series | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Orientation | |
| Packaging Type | |
| Pitch | |
| Prop 65 | |
| Row Spacing | |
| SVHC Present | |
| Standard Package Quantity | |
| Style | |
| Tape & Reel | |
| Termination |
The Samtec SLM-112-01-S-D is a 24 position, 2 row, through hole receptacle connector from the SLM series. It features a 1.27mm (0.050") pitch between contacts and a 2.54mm (0.100") row spacing, designed for board to board stacking applications. The connector uses a push-pull fastening type and is oriented vertically.
The receptacle is constructed with a black glass filled polyester insulator and phosphor bronze contacts with a 30µin gold finish on the contact area and matte tin on the tail. It is rated for an operating temperature range of -55°C to +125°C and has a typical current rating of 5.2A per pin with 2 pins powered.
The SLM-112-01-S-D is packaged in tubes with a standard quantity of 37 pieces per tube. It is RoHS3 compliant and REACH compliant with no SVHCs. The part mates with Samtec HTMS, TMS, MTMS, DWM, HDWM, FTR, and HMTMS series connectors.
| Qty | Low | High |
|---|---|---|
| 1+ | $4.90 | $4.90 |
| 25+ | $4.55 | $4.55 |
| 37+ | $4.54 | $4.54 |
| 111+ | $4.29 | $4.29 |
| 518+ | $4.14 | $4.14 |
| 1,036+ | $4.01 | $4.01 |
| 2,516+ | $3.89 | $3.89 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 1.27mm (0.050") between contacts and 2.54mm (0.100") between rows.
It has 24 positions arranged in 2 rows.
It is a through hole mounting connector with solder termination.
The typical current rating is 5.2A per pin with 2 pins powered.
The operating temperature range is -55°C to +125°C.
The contact finish is 30µin gold on the contact area and matte tin on the tail.
It mates with Samtec HTMS, TMS, MTMS, DWM, HDWM, FTR, and HMTMS series connectors.
