| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
14,800 pcs
|
14800 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1,772 pcs
|
1772 pcs | On Request | 1 | On Request | On Request | 1817+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Material | |
| Current Rating | |
| Industrial Grade | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Style | |
| Termination | |
| Termination Style | |
| Wire Gauge | |
| Withstanding Voltage |
The JST SLEB-001T-P0.2 is a crimp-type tab contact designed for use in solid state lighting (SSL) connectors. It is part of the SLEB series and is intended for board-to-cable/wire connections.
This contact accepts 22 to 26 AWG wire and features a tin-plated copper alloy construction. It is rated for a maximum current of 5 A (AC/DC) and a voltage of 300 V (AC/DC). The contact resistance is 13 mΩ maximum initially and 15 mΩ maximum after environmental tests. Insulation resistance is a minimum of 100 MΩ, and the withstanding voltage is 1500 V AC for one minute.
The SLEB-001T-P0.2 is a free hanging (in-line) contact with a crimp termination style. It operates over a temperature range of -55°C to 105°C.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.10 | $0.10 |
| 10+ | $0.04 | $0.04 |
| 25+ | $0.04 | $0.04 |
| 100+ | $0.04 | $0.04 |
| 250+ | $0.03 | $0.03 |
| 1,000+ | $0.03 | $0.03 |
| 2,500+ | $0.03 | $0.03 |
| 5,000+ | $0.03 | $0.03 |
| 10,000+ | $0.03 | $0.03 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The SLEB-001T-P0.2 accepts 22 to 26 AWG wire.
The maximum current rating is 5 A (AC/DC).
The operating temperature range is -55°C to 105°C.
The contact is made of copper alloy with a tin finish.
The mounting style is free hanging (in-line).
