SL-108-G-11

The SL-108-G-11 is an 8-position single row low profile screw machine socket strip from Samtec's SL series. It features a receptacle connector with female socket contacts, arranged in a single row at a 2.54mm (0.100") pitch. The contacts are made of beryllium copper with a 30 µ" (0.76 µm) gold contact finish and a 10 µ" (0.25 µm) gold shell plating. The insulator is black liquid crystal polymer, and the shell is brass. This through hole component uses solder termination and a push-pull fastening type. The operating temperature range spans -55°C to 125°C, making it suitable for a wide range of environments. The low profile design (insulation height 3.35mm) allows for compact board stacking when mated with Samtec's BBL or BDL terminal strips. The lead style is Style 11, with a contact length of 2.75mm and an accepted lead diameter of 0.41mm to 0.53mm. The insertion depth ranges from 2.03mm to 2.67mm. Packaging is bulk. The product is RoHS3 compliant, REACH unaffected, halogen free, and has a moisture sensitivity level of 1. It is designed for board-to-board applications and is compatible with mating connectors such as Samtec's TS, BBL, and HTS terminal strips.
