SGM3752YTN6G/TR
SG Micro Corp
The SG Micro Corp SGM3752YTN6G/TR is a 38V high-efficiency Boost White LED Driver with PWM dimming control. It operates from a 2.7V to 5.5V input voltage range.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
17,100 pcs
|
17100 pcs | On Request | 1 | On Request | On Request | 18/19 | On Request | On Request | |
|
1,000 pcs
|
1000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Halogen Free | |
| Input Voltage | |
| Operating Temperature | |
| SVHC Present | |
| Tape & Reel |
The SGM3732YTN6G/TR is a high-efficiency, constant current LED driver from SG Micro Corp, utilizing a 1.1MHz PWM boost converter. It is designed for compact solutions and can drive up to 10 LEDs in series for a 38V output or a total of 260mA with 3 LEDs per string. The LED current is programmable via a digital PWM dimming interface, with a dimming frequency range of 2kHz to 60kHz.
Key electrical features include an input voltage range of 2.7V to 5.5V, an integrated 40V/1.35A switch, and a low feedback voltage of 200mV. The device also incorporates protection features such as over-voltage protection, cycle-by-cycle input current limit, and thermal shutdown. It offers a very low shutdown current of less than 1µA and automatic soft-start to reduce inrush current.
This LED driver operates within an ambient temperature range of -40℃ to +85℃ and is available in a green TSOT-23-6 package. Its applications include LED backlighting for mobile phones, digital photo frames, portable devices, and automotive navigation systems.
The input voltage range is 2.7V to 5.5V.
The switching frequency is 1.1MHz.
The operating temperature range is -40℃ to +85℃.
It is available in a TSOT-23-6 package.
Yes, it supports digital PWM dimming with a frequency range of 2kHz to 60kHz.
It provides 38V LED open protection.
The shutdown current is less than 1µA.
