| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
12 pcs
|
12 pcs | On Request | 1 | On Request | On Request | 08+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Base Resonator | |
| Current | |
| Frequency | |
| Frequency Stability | |
| Function | |
| Height | |
| Industrial Grade | |
| Lead Style | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Operating Temperature | |
| Output | |
| SVHC Present | |
| Storage Temperature | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Width |
The SG-710ECK 25.0000MB is a surface-mount crystal oscillator (SPXO) from Epson's SG-710 series. It provides a stable 25 MHz output with CMOS logic levels. Key electrical specifications include a supply voltage of 3.3 V, frequency stability of ±50 ppm, and maximum current consumption of 8 mA (no load, f0 ≤ 25 MHz). The oscillator features a Standby (Power Down) function that reduces current to 13 µA when activated.
Designed for general-purpose timing applications, the SG-710ECK offers fast start-up time of 10 ms and rise/fall times of 5 ns. The output frequency symmetry is 45% to 55% under 15 pF CMOS load. Frequency aging is ±5 ppm in the first year.
Housed in a compact 4-SMD, No Lead package measuring 7.30 mm x 4.80 mm x 1.40 mm, this oscillator is suitable for automated surface mount assembly. The operating temperature range is -10°C to +70°C.
25 MHz
±50 ppm
3.3 V
CMOS
-10°C to 70°C
4-SMD, No Lead
Yes, RoHS3 Compliant (unverified)
