| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,000 pcs
|
3000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Material | |
| Cable End Type | |
| Connector | |
| Contact Finish | |
| Contact Material | |
| FFC, FCB Thickness | |
| Features | |
| Flat Flex Type | |
| Height Above Board | |
| Housing Material | |
| Locking Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Tape & Reel | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The Amphenol ICC SFV4R-1STE1HLF is a surface mount, right angle FFC/FPC connector with 4 positions and a 0.5mm pitch. It features bottom contacts and a slide lock mechanism for secure cable retention. The connector is rated for 50V and operates over a temperature range of -55°C to 105°C. The housing is made of halogen-free, glass-filled polyamide (nylon) with UL94 V-0 flammability rating, and the actuator is made of halogen-free, glass-filled polyphenylene sulfide (PPS). Contacts are phosphor bronze with tin plating. The connector supports FFC/FPC cables with a thickness of 0.3mm. Termination is solder. The height above board is 1.8mm. This connector is designed for applications requiring a compact, reliable connection for flat flexible cables.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.40 | $0.40 |
| 10+ | $0.34 | $0.34 |
| 25+ | $0.31 | $0.31 |
| 100+ | $0.29 | $0.29 |
| 250+ | $0.26 | $0.26 |
| 1,000+ | $0.25 | $0.25 |
| 2,500+ | $0.23 | $0.23 |
| 6,000+ | $0.21 | $0.21 |
| 12,000+ | $0.20 | $0.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
4 positions.
0.5mm.
50V.
Surface Mount, Right Angle.
-55°C to 105°C.
Slide Lock.
Phosphor bronze with tin plating.
