| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
19 pcs
|
19 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Circuit Type | |
| Lead Spacing | |
| Length | |
| Mounting Type | |
| Number of Pins | |
| Number of Resistors | |
| Operating Temperature | |
| Power Per Element | |
| Resistance (Ohms) | |
| Resistor | |
| Resistor Matching Ratio | |
| Storage Temperature | |
| Supplier Device Package | |
| Tape & Reel | |
| Temperature Coefficient | |
| Tolerance | |
| Width |
This TT Electronics/BI SFN08B1001CBQLF7 is a thin film resistor network featuring 7 individual resistors configured in a bussed circuit type. Each resistor has a nominal resistance of 1k Ohm with a tolerance of ±0.25% and a power rating of 100mW at 70°C. The network offers a TCR tracking tolerance of ±5ppm/°C and an absolute temperature coefficient of ±25ppm/°C, operating within a temperature range of -55°C to +125°C.
The component is housed in an 8-pin DFN (Dual Flat No-lead) package, specifically an 8-SON (Small Outline No-lead) measuring 4mm x 4mm with a 0.8mm pitch. It is designed for surface mounting, making it suitable for high-density PCB layouts. The passivation coating provides protection in humid environments, and the Nichrome resistors on silicon offer precision performance.
This resistor network is RoHS3 compliant and has a Moisture Sensitivity Level (MSL) of 1. It is suitable for applications requiring precise resistance ratios and stable temperature performance.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance value is 1k Ohm.
The tolerance is ±0.25%.
There are 7 resistors in this network.
The operating temperature range is -55°C to +125°C.
It uses an 8-DFN Exposed Pad package.
Yes, it is RoHS3 Compliant.
