SFM-135-01-S-D-A

The Samtec SFM-135-01-S-D-A is a high-density 70-position female socket receptacle designed for board-to-board or cable applications. It features a 1.27mm pitch, 2 rows, and all positions loaded. The connector is rated for 3.2A per contact and 250VAC, with an operating temperature range of -55°C to 125°C. It offers a push-pull fastening type with a board guide feature for secure mating. The contact finish is tin with a thickness of 30.0µin (0.76µm). The insulation is black, rated UL94 V-0, with an insulation height of 4.57mm. Through-hole solder termination ensures reliable connections. The connector supports multiple mated stacking heights from 6.02mm to 11.63mm, providing flexibility in design. The row spacing matches the pitch of 1.27mm. This component is suitable for dense signal interconnects in industrial, automotive, and consumer electronics.
