Mfr Part #:

SFC-120-T2-L-D-A-K-TR

Samtec SFC-120-T2-L-D-A-K-TR is a 40 position, 1.27mm pitch surface mount receptacle with female socket contacts. It is rated for 3.1A per contact and 350VAC.

✓ Total Stock: 1,650 pcs

$ Price Range: $3.17 - $4.16

SFC-120-T2-L-D-A-K-TR Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Braun Electronic Components ✓ Non-Authorised Inventory information	1,650 pcs On Request	1650 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

SFC-120-T2-L-D-A-K-TR Description

Short technical summary and product information.

The Samtec SFC-120-T2-L-D-A-K-TR is a 40-position, 1.27mm pitch receptacle from the SFC series of Tiger Eye systems. This connector features a push-pull fastening type and is designed for board-to-board or cable applications. It has a black LCP insulator with a height of 4.57mm and includes board guide and pick-and-place features for automated assembly.

The receptacle uses phosphor bronze contacts with a tin finish (10.0µin thickness) and is rated for a current of 3.1A per contact and a voltage of 350VAC. It operates over a temperature range of -55°C to 125°C. The connector is surface mount with solder termination and is supplied on tape and reel. It is lead-free solderable.

SFC-120-T2-L-D-A-K-TR Quick Information

Product Type: Receptacle

Series: SFC

Canonical Name: Samtec SFC Series 40 Position 1.27mm Pitch Surface Mount Receptacle

Subcategory: Headers, Receptacles, Female Sockets

SFC-120-T2-L-D-A-K-TR Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Lead Free: Yes

SFC-120-T2-L-D-A-K-TR Estimated Pricing

Qty	Low	High
1+	$4.16	$4.16
25+	$4.13	$4.13
50+	$4.00	$4.00
100+	$3.43	$3.43
550+	$3.43	$3.43
1,100+	$3.42	$3.42
2,200+	$3.17	$3.17

Estimated market price range - modelled values for guidance only, not live distributor offers.

SFC-120-T2-L-D-A-K-TR Features

40 position 1.27mm pitch receptacle.
Surface mount with solder termination.
Rated for 3.1A per contact and 350VAC.
Push-pull fastening type for secure mating.
Includes board guide and pick-and-place features.

SFC-120-T2-L-D-A-K-TR Applications

Ideal for board-to-board interconnections.
Suitable for cable-to-board applications.
Used in high-density electronic assemblies.

SFC-120-T2-L-D-A-K-TR FAQs

7 frequently asked questions generated from this part’s specifications.

How many positions does the SFC-120-T2-L-D-A-K-TR have?

It has 40 positions in 2 rows.

What is the pitch of this connector?

The pitch is 1.27mm (0.050").

What is the current rating of the SFC-120-T2-L-D-A-K-TR?

The current rating is 3.1A per contact.

What is the voltage rating of this connector?

The voltage rating is 350VAC.

What is the mounting type for this part?

It is a surface mount connector with solder termination.

What is the operating temperature range?

The operating temperature range is -55°C to 125°C.

What is the contact finish on this receptacle?

The contact finish is tin with a thickness of 10.0µin (0.25µm).

Category	Headers, Receptacles, Female Sockets
Manufacturer Name	Samtec Inc.
Connector Type	Receptacle
Contact Finish	Tin
Contact Finish Thickness	10.0µin (0.25µm)
Contact Type	Female Socket
Current Rating (Amps)	3.1A per Contact
Fastening Type	Push-Pull
Features	Board Guide, Pick and Place
Insulation Color	Black
Insulation Height	4.57mm (0.180")
Lead Spacing	1.27 mm
Lead Style	Smd
Mounting Type	Surface Mount
Number of Positions	40
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature	-55°C ~ 125°C
Pitch	1.27mm (0.050")
Row Spacing	0.050" (1.27mm)
Style	Board to Board or Cable
Tape & Reel	Yes
Termination	Solder
Termination Style	Solder
Voltage Rating	350VAC
