SEAF-40-06.5-S-08-2-A Samtec SEAF-40-06.5-S-08-2-A is a .050" (1.27mm) pitch high density array receptacle with 320 positions. It features gold-plated contacts, surface mount termination, and supports stack heights from 8.5mm to 19.5mm.
Mfr Part #:

SEAF-40-06.5-S-08-2-A

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
Samtec SEAF-40-06.5-S-08-2-A is a .050" (1.27mm) pitch high density array receptacle with 320 positions. It features gold-plated contacts, surface mount termination, and supports stack heights from 8.5mm to 19.5mm.
✓ Total Stock: 7 pcs
$ Price Range: $16.96

SEAF-40-06.5-S-08-2-A Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
7 pcs
On Request
7 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

SEAF-40-06.5-S-08-2-A Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Material
Current Rating
Features
Halogen Free
Height Above Board
Insulator Material
Lead Spacing
Lead Style
Mated Stacking Heights
Mounting Type
Number of Positions
Number of Rows
Operating Temperature Range
Pitch
Tape & Reel
Termination Style
Voltage Rating
View Similar Products (0)

SEAF-40-06.5-S-08-2-A Description

Short technical summary and product information.

The SEAF-40-06.5-S-08-2-A is part of Samtec's SEARAY™ family of open-pin-field array connectors. This receptacle has 320 positions arranged in 8 rows at a 1.27mm pitch, providing high density for board-to-board mezzanine applications. The contacts are gold-plated with 30µin (0.76µm) thickness over copper alloy, and the insulator is black LCP. The surface mount termination uses solder charge technology for reliable reflow soldering.



Electrical ratings are 2.7A per pin (10 pins powered) and 240 VAC/339 VDC maximum. The operating temperature range is -55°C to +125°C. Mated stacking heights of 8.5mm, 9.5mm, 10mm, 13mm, 13.5mm, 15.5mm, 17.5mm, and 19.5mm are supported. The connector includes a board guide feature for alignment.



This connector is designed for high-speed signals up to 56 Gbps PAM4 with the Edge Rate® contact system, offering high mating cycles and robust performance. It is packaged in Tape & Reel with 200 parts per reel. Compliance to RoHS is indicated but unverified; the part is also marked as REACH unaffected.

SEAF-40-06.5-S-08-2-A Quick Information

Product Type: High Density Array, Mezzanine (Board to Board) Socket
Series: SEAF
Canonical Name: SEAF-40-06.5-S-08-2-A | .050" SEARAY High-Speed High-Density Open-Pin-Field Array Socket, Receptacle, 320 Positions, Surface Mount, Gold
Subcategory: Mezzanine (Board-to-Board) Connector

SEAF-40-06.5-S-08-2-A Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): Moisture Sensitivity Level 1 (Unlimited)
REACH Status: REACH Unaffected

SEAF-40-06.5-S-08-2-A Estimated Pricing

Qty Low High
125+ $16.96 $16.96

Estimated market price range - modelled values for guidance only, not live distributor offers.

SEAF-40-06.5-S-08-2-A Features

  • 320 positions in 8 rows.
  • 1.27mm pitch for high density.
  • Gold contact finish with 30µin thickness.
  • Surface mount with solder charge termination.
  • Rated for 2.7A and 240 VAC.

SEAF-40-06.5-S-08-2-A Applications

  • Mezzanine board-to-board high density interconnects.
  • High-speed data transmission up to 56 Gbps.
  • Automotive and industrial harsh environment applications.
  • Differential pair and single-ended signal routing.
  • Power, signal, and ground distribution in arrays.

SEAF-40-06.5-S-08-2-A FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the SEAF-40-06.5-S-08-2-A have?

320 positions.

What is the pitch of this connector?

1.27 mm (0.050").

What is the current rating of the SEAF-40-06.5-S-08-2-A?

2.7 A (10 pins powered).

What is the voltage rating?

240 VAC / 339 VDC maximum.

What is the mounting type?

Surface mount with solder charge termination.

What is the operating temperature range?

-55°C to +125°C.

What mated stacking heights are supported?

8.5mm, 9.5mm, 10mm, 13mm, 13.5mm, 15.5mm, 17.5mm, 19.5mm.
