SEAF-30-05.0-S-08-2-A-K-TR .050" (1.27mm) pitch high-density array receptacle connector with 240 positions in 8 rows, rated for 56 Gbps PAM4 performance and surface mount termination.
Mfr Part #:

SEAF-30-05.0-S-08-2-A-K-TR

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
.050" (1.27mm) pitch high-density array receptacle connector with 240 positions in 8 rows, rated for 56 Gbps PAM4 performance and surface mount termination.
✓ Total Stock: 2 pcs
$ Price Range: $10.66 - $17.07

SEAF-30-05.0-S-08-2-A-K-TR Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
2 pcs
On Request
2 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

SEAF-30-05.0-S-08-2-A-K-TR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Material
Current Rating
Data Rate
Features
Halogen Free
Height Above Board
Insulator Material
Lead Spacing
Lead Style
Mated Stacking Heights
Mating Cycles
Mounting Type
Number of Positions
Number of Rows
Operating Temperature Range
Pitch
Plating
Tape & Reel
Voltage Rating
View Similar Products (0)

SEAF-30-05.0-S-08-2-A-K-TR Description

Short technical summary and product information.

The Samtec SEAF-30-05.0-S-08-2-A-K-TR is a .050" (1.27mm) pitch, open-pin-field array receptacle connector from the SEARAY family. It features 240 positions arranged in 8 rows with 30µin gold contact finish on a copper alloy base, housed in a black LCP insulator. The connector supports 56 Gbps PAM4 data rates and is rated for 2.7A (10 pins powered) and 240 VAC/339 VDC.



Designed for board-to-board mezzanine applications, the SEAF series utilizes the Edge Rate contact system for high mating cycles—certified to 5,000 cycles as an Extended Life Product. Mated stacking heights range from 7mm to 18mm, offering flexibility in system design. The connector includes board guide and pick-and-place features for automated assembly.



Packaged in Tape & Reel with a standard quantity of 250 pieces, the part is lead-free solderable and surface-mountable. Operating temperature range is -55°C to +125°C, making it suitable for a wide range of environments.

SEAF-30-05.0-S-08-2-A-K-TR Quick Information

Product Type: Array Receptacle Connector
Series: SEAF
Canonical Name: .050" SEARAY High-Speed 56Gbps Array Receptacle Connector, 240 Pin, 8 Row, 30µin Gold/Tin, 5mm Ht, RoHS, A Pin, K Pad, Tape & Reel
Subcategory: High-Density Array Connector

SEAF-30-05.0-S-08-2-A-K-TR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

SEAF-30-05.0-S-08-2-A-K-TR Estimated Pricing

Qty Low High
1+ $17.07 $17.07
10+ $14.51 $14.51
25+ $13.61 $13.61
50+ $12.96 $12.96
250+ $12.80 $12.80
500+ $11.24 $11.24
1,000+ $10.66 $10.66

Estimated market price range - modelled values for guidance only, not live distributor offers.

SEAF-30-05.0-S-08-2-A-K-TR Features

  • .050" (1.27mm) pitch high-density array.
  • 240 positions in 8 rows for dense routing.
  • 56 Gbps PAM4 high-speed data performance.
  • Extended Life Product certified to 5,000 cycles.
  • Gold plated contacts for reliable connectivity.

SEAF-30-05.0-S-08-2-A-K-TR Applications

  • Suitable for high-speed board-to-board mezzanine connections.
  • Ideal for data center and telecom equipment backplanes.
  • Used in test and measurement instrumentation.
  • Designed for automated surface mount assembly lines.

SEAF-30-05.0-S-08-2-A-K-TR FAQs

7 frequently asked questions generated from this part’s specifications.
What is the number of positions and row configuration of this connector?

The connector has 240 positions arranged in 8 rows.

What is the pitch of the SEAF-30-05.0-S-08-2-A-K-TR?

The pitch is 1.27mm (0.050").

What is the current and voltage rating of this receptacle?

Current rating is 2.7 A (10 pins powered). Voltage rating is 240 VAC / 339 VDC.

What mounting type does this connector use?

It uses Surface Mount (SMT) termination.

What is the maximum data rate supported by this connector?

It supports 56 Gbps PAM4 data rate.

What are the mated stacking heights possible with this part?

Mated stacking heights include 7mm, 8mm, 8.5mm, 11.5mm, 12mm, 14mm, 16mm, and 18mm.

What is the operating temperature range and mating cycle rating?

Operating temperature range is -55°C to +125°C. It is rated for 5,000 mating cycles (Extended Life Product).
