| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,000 pcs
|
2000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Frequency | |
| Height | |
| Inductance | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Self Resonant Frequency | |
| Shielding | |
| Standard Package Quantity | |
| Termination Style | |
| Tolerance | |
| Type | |
| Width |
The API Delevan SDS680R-105M is a fixed inductor designed for surface mount applications. It features a wirewound drum core construction with a ferrite material, providing a shielded design for reduced electromagnetic interference.
Key electrical specifications include an inductance of 1 mH with a tolerance of ±20%. It is rated for a maximum DC current of 150 mA and has a maximum DC resistance of 3.4 Ohms. The inductor operates effectively within a temperature range of -40°C to 85°C and has a self-resonant frequency of 2 MHz.
Mechanically, the SDS680R-105M measures 6.60mm in length, 4.45mm in width, and 2.92mm in height. It is supplied on a reel, with a standard factory pack quantity of 2000 units. This component is suitable for power applications.
Compliance information indicates RoHS3 compliance and MSL 1 rating. The REACH status is unaffected.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.20 | $0.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
1 mH.
150 mA.
3.4 Ohms.
2 MHz.
-40°C to 85°C.
Yes, it is shielded.
6.60mm x 4.45mm x 2.92mm.
