The SolaHD SDN-PMBRK3 is an accessory designed for the SolaHD SDN-D series of high-performance DIN rail power supplies. This kit allows for the conversion of standard DIN rail mounting to a direct panel or chassis mount configuration. It replaces the existing DIN mounting brackets on the back of the unit with two panel mount brackets.
The kit includes two panel mount brackets, two M3x8 mm Phillips screws, and two lock washers for securing the brackets. It also includes four 8-32 x 1/2” screws and four 8-32 flat washers for mounting the unit to a panel. The installation process involves removing the original DIN brackets and sliding the new panel mount brackets into place, securing them with the provided hardware. The dimensions of the panel mount bracket are approximately 1.65 inches (41.9 mm) in length, 0.87 inches (22.1 mm) in width, and 0.60 inches (15.2 mm) in height.
This accessory is crucial for applications where DIN rail mounting is not feasible and a more permanent, direct integration into control panels or enclosures is required. It ensures the reliable and secure mounting of SolaHD SDN-D power supplies in various industrial environments.
The SolaHD SDN-PMBRK3 is a panel mount bracket kit designed to convert compatible SDN-D series power supplies from DIN rail mounting to direct panel or chassis mounting.
The accessory type is Bracket - Panel Mount.
The SDN-PMBRK3 is for use with the SDN™ Series power supplies.
The SDN-PMBRK3 is a panel mount bracket.
