| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
127 pcs
|
127 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| California Proposition 65 | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Type | |
| Fastening Type | |
| Insertion Depth | |
| Insulation Color | |
| Insulation Height | |
| Insulator Material | |
| Lead Diameter Accepted | |
| Lead Style | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Packaging Type | |
| Pitch | |
| Plating Contact | |
| Plating Shell | |
| Row Spacing | |
| Shell Material | |
| Standard Package Quantity | |
| Style | |
| Tape & Reel | |
| Termination | |
| UL Recognition |
The Samtec SDL-116-T-10 is a 32-position double row low profile screw machine socket strip from the SDL series. It features a 2.54mm (0.100") pitch and row spacing, with a through hole mounting style and solder termination. The connector uses a push-pull fastening system and is designed for board-to-board applications.
The receptacle houses 32 female socket contacts made of beryllium copper with a 30 µ" (0.76 µm) gold plating. The shell is made of brass with a tin plating. The insulator is black glass filled polyester, with an insulation height of 3.10mm (0.122"). The connector accepts lead diameters from 0.41mm to 0.51mm and has an insertion depth of 2.67mm to 4.32mm for Style 10 leads.
Packaged in a tube with 14 parts per tube, the SDL-116-T-10 operates over a temperature range of -55°C to 125°C. It is RoHS3 compliant, REACH unaffected, and has UL recognition (File No. E111594).
| Qty | Low | High |
|---|---|---|
| 1+ | $7.28 | $7.28 |
| 28+ | $6.58 | $6.58 |
| 56+ | $6.11 | $6.11 |
| 112+ | $5.78 | $5.78 |
| 504+ | $4.96 | $4.96 |
| 1,008+ | $4.34 | $4.34 |
| 2,506+ | $3.96 | $3.96 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
32 positions in a double row configuration, all positions loaded.
2.54mm (0.100") pitch with the same 2.54mm row spacing.
Through hole mounting with solder termination.
Beryllium copper female socket contacts with 30 µ" (0.76 µm) gold plating. Shell is brass with tin plating.
-55°C to 125°C.
Yes, RoHS3 compliant. Also REACH unaffected and UL recognized (E111594).
