| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,000 pcs
|
1000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Frequency | |
| Halogen Free | |
| Heating Current | |
| Height | |
| Inductance | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Ratings | |
| Saturation Current | |
| Shielding | |
| Tape & Reel | |
| Tolerance | |
| Type | |
| Width |
The Bourns SDE0805A-180M is a surface-mount, unshielded SMD power inductor from the SDE0805A series. It offers an inductance value of 18µH with a tolerance of ±20% and a maximum DC resistance of 0.1Ω.
This inductor is designed for high saturation current applications, rated at 2.45A for heating current and 2.0A for saturation current. It operates within a temperature range of -40°C to +125°C and is AEC-Q200 qualified, making it suitable for automotive and industrial environments. The core material is ferrite, and the terminals are Sn-plated copper wire.
With dimensions of 7.80mm x 7.00mm x 5.50mm, the SDE0805A-180M is provided in a nonstandard package, typically supplied on a reel of 1000 pieces. It is RoHS compliant and halogen-free.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.20 | $0.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance is 18 µH, measured at 1 MHz / 1 V.
The current rating is 2.45 A.
The maximum DC resistance is 0.1 Ω.
The self-resonant frequency is 17.6 MHz.
The package is a nonstandard surface mount package.
The operating temperature range is -40°C to +125°C.
Yes, it is AEC-Q200 qualified.
