| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,104 pcs
|
1104 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| AEC-Q200 | |
| Automotive Grade | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Frequency | |
| Halogen Free | |
| Height | |
| Inductance | |
| Inductance Drop | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Ratings | |
| Shielding | |
| Storage Temperature | |
| Temperature Rise | |
| Terminal Finish | |
| Test Frequency / Voltage | |
| Tolerance | |
| Type | |
| Width | |
| Wire Material |
The Bourns SDE0403A-180M is a high-performance SMD power inductor from the SDE0403A series. It offers an inductance value of 18µH with a tolerance of ±20% and a maximum DC resistance of 309mOhm. This inductor is rated for a continuous current of 750mA (Irms) and a saturation current of 1.1A (Isat).
Designed for operation within a temperature range of -40°C to 125°C, the SDE0403A-180M features a ferrite core and enameled copper wire. Its compact dimensions of 4.5 x 4 x 3.2 mm make it suitable for space-constrained applications. The inductor is AEC-Q200 compliant, indicating its suitability for automotive and other high-reliability environments.
This unshielded, drum core inductor is supplied in a standard package of 2000 pieces per reel, designed for surface mounting. Its robust construction and electrical characteristics make it a reliable choice for various power management circuits.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.20 | $0.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal inductance is 18µH at 25°C.
The RMS current rating is 750mA and the saturation current is 1.1A at 25°C.
The maximum DC resistance is 309mOhm at 25°C.
The self-resonant frequency is 28MHz at 25°C.
The operating temperature range is -40°C to +125°C.
Yes, it is AEC-Q200 compliant.
It is a surface mount component in a nonstandard package.
