SD06/TR The SGMICRO SD06/TR is a dual operational amplifier with a 6MHz gain bandwidth product and rail-to-rail input/output capabilities. It is designed for low voltage, low noise applications.
Mfr Part #:

SD06/TR

Available from 2 distributors
Mfr Name: SGM
SGM
The SGMICRO SD06/TR is a dual operational amplifier with a 6MHz gain bandwidth product and rail-to-rail input/output capabilities. It is designed for low voltage, low noise applications.
✓ Total Stock: 3,500 pcs

SD06/TR Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Smaxon Electronics ✓
Non-Authorised Inventory information
2,500 pcs
On Request
2500 pcs On Request 1 On Request On Request 15+ On Request On Request
Optech Co.,Limited ✓
Non-Authorised Inventory information
1,000 pcs
On Request
1000 pcs On Request 1 On Request On Request 15+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

SD06/TR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Operating Temperature
Output Current
Package / Case
Quiescent Current
Slew Rate
Tape & Reel
View Similar Products (0)

SD06/TR Description

Short technical summary and product information.

The SGMICRO SD06/TR is a dual, low-noise, low-voltage, low-power CMOS operational amplifier. It offers a gain bandwidth product of 6MHz and a slew rate of 3.7V/μs, consuming only 960μA of static current at 5V. Designed for optimal performance in low-voltage, low-noise systems, the SD06/TR provides rail-to-rail output swing even under heavy loads.



This operational amplifier supports single supply voltages from 2V to 5.5V and dual supply voltages from ±1V to ±2.75V. It features rail-to-rail input and output, making it suitable for a wide range of applications. The device is available in a SOIC-8 package.



Key electrical characteristics include an input offset voltage of 3.5mV, input bias current of 1pA, and output current capability of 51mA. The operating temperature range is -40°C to +125°C.

SD06/TR Quick Information

Product Type: Operational Amplifier
Canonical Name: SD06/TR Dual Operational Amplifier
Subcategory: Dual Operational Amplifier

SD06/TR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

SD06/TR Features

  • Dual rail-to-rail input/output op-amp.
  • 6MHz gain bandwidth product.
  • 3.7V/us slew rate.
  • Low static current of 960μA.
  • Wide operating temperature range.

SD06/TR Applications

  • Suitable for low voltage systems.
  • Ideal for low noise applications.
  • Provides rail-to-rail output swing.
  • Designed for broad application use.

SD06/TR FAQs

7 frequently asked questions generated from this part’s specifications.
What is the gain bandwidth product of the SD06/TR?

6 MHz typical.

Does the SD06/TR support rail-to-rail operation?

Yes, it has rail-to-rail input and output.

What is the supply voltage range for the SD06/TR?

Single supply 2V to 5.5V, or dual supplies ±1V to ±2.75V.

What is the input offset voltage of the SD06/TR?

3.5 mV typical.

What is the operating temperature range?

-40°C to +125°C.

What package does the SD06/TR come in?

SOIC-8.

What is the typical quiescent current?

960 µA at 5V supply.
