| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,500 pcs
|
2500 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Control Features | |
| Current | |
| Mounting Type | |
| Number of Outputs | |
| Number of Regulators | |
| Operating Temperature | |
| Output Configuration | |
| Output Type | |
| PSRR | |
| Protection Features | |
| Supplier Device Package | |
| Voltage | |
| Voltage Dropout (Max) |
The Rohm Semiconductor BAJ2CC0WT-V5 is a linear voltage regulator designed for power management applications. It features a fixed 12V output voltage and can supply up to 1A of current. The device accepts an input voltage up to 25V and operates with a quiescent current of 2.5 mA. Protection features include over current, over temperature, and over voltage.
This regulator is housed in a TO-220-5 Full Pack package and is designed for through-hole mounting. It has an operating temperature range of -40°C to 125°C. The device offers line regulation of 100 mV and load regulation of 150 mV, with a voltage regulation accuracy of 2%. Its PSRR is rated at 55dB at 120Hz.
The BAJ2CC0WT-V5 is RoHS3 compliant and REACH unaffected, making it suitable for various electronic designs requiring stable voltage regulation.
| Qty | Low | High |
|---|---|---|
| 1+ | $23.40 | $23.40 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The BAJ2CC0WT-V5 has a fixed output voltage of 12V.
The BAJ2CC0WT-V5 can provide a maximum output current of 1A.
The maximum input voltage for the BAJ2CC0WT-V5 is 25V.
The BAJ2CC0WT-V5 is supplied in a TO-220-5 Full Pack package.
The BAJ2CC0WT-V5 operates between -40°C and 125°C.
Yes, the BAJ2CC0WT-V5 includes over current protection features.
