The Bel Power Solutions SBLP65-1048G is an open-frame AC/DC converter designed for ITE (Commercial) applications. It delivers a 48V output voltage with a maximum output current of 1.56A, providing up to 60W of power, or 65W with forced air cooling.
Key features include adjustable output, remote sense, and universal input, operating from 90 to 264 VAC. The converter boasts an efficiency of 85% and an isolation voltage of 4.242kV. Its dimensions are 101.6mm x 50.8mm x 33.0mm.
This chassis mountable unit is suitable for various industrial automation and process automation systems. It operates within a temperature range of -10°C to 70°C with derating. The standard package quantity is 50 units.
The output voltage is 48V and the maximum output current is 1.56A.
The input voltage range is 90 to 264 VAC.
The operating temperature range is -10°C to 70°C with derating.
The efficiency is 85%.
The isolation voltage is 4.242kV.
The dimensions are 101.6mm x 50.8mm x 33.0mm (4.00" x 2.00" x 1.30").
It uses chassis mount.
