| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Width |
The Omron S8VM-15024A is an enclosed AC/DC converter designed for commercial ITE (Information Technology Equipment) applications. It delivers a single output of 24V at 7A, providing 150W of power with an efficiency rating of 83%.
This converter features a universal input and an adjustable output, offering flexibility for various system requirements. It is designed for chassis mount installation, with dimensions of 164.5mm in length, 44.0mm in width, and 84.5mm in height. The operating temperature range is -10°C to 70°C with derating.
The S8VM-15024A holds multiple safety approvals including CE, cULus, cURus, and VDE, ensuring compliance with international standards for commercial equipment. Its enclosed design provides protection for the internal components.
The Omron S8VM-15024A provides a single output of 24V at 7A.
The S8VM-15024A is rated for 150W.
The efficiency is 83%.
The operating temperature range is -10°C to 70°C with derating.
The S8VM-15024A uses chassis mount.
The dimensions are 164.5mm (length) x 44.0mm (width) x 84.5mm (height).
It holds CE, cULus, cURus, and VDE approvals.
