The Omron S8E3-05031A is an AC/DC converter designed for ITE (Commercial) applications. This open frame unit delivers 50W of power and offers an adjustable output.
Key electrical specifications include a 50W power rating and a current output of 500 mA. It provides multiple voltage outputs, including +5V, -12V, and another unspecified output, indicated by the '3 Outputs' feature. The operating temperature range is -10°C to 70°C with derating.
Mechanically, the converter is designed for chassis mounting and has dimensions of 193.5mm in length, 69.0mm in width, and 33.0mm in height. It is approved by CSA and UR.
Environmental compliance includes RoHS3 compliance, MSL Level 1, and REACH unaffected status. The efficiency is rated at 73%.
The converter provides three outputs: 5V, +12V, and -12V.
3 outputs.
50W.
73%.
-10°C to 70°C with derating.
CSA and UR approved.
Chassis mount.
