| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Frequency | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Overload Protection | |
| Power (Watts) | |
| Ripple | |
| SVHC Present | |
| Type | |
| Voltage | |
| Width |
The Omron S8E1-05024D is an open-frame AC/DC converter designed for ITE (Commercial) applications. It delivers a 50W output power with a nominal voltage of 24V and a current rating of 2.2A.
This converter operates with an input voltage range of 85 to 132 VAC and a frequency of 47 to 450 Hz. It offers an efficiency typically between 73% and 83%. Key electrical specifications include a ripple of 2% (p-p) maximum, input variation influence of 0.4% maximum, and load variation influence of 0.8% maximum.
Mechanical specifications include dimensions of 161.0mm x 69.0mm x 37.0mm, making it suitable for chassis mounting. The operating temperature range is -10°C to 70°C with derating. Additional features include adjustable output, DC input capability, and universal input.
The S8E1-05024D is approved by CSA and UR agencies. It also includes overload protection at 105% minimum of rated load current and overvoltage protection for 5V output models.
24 V
Open frame
-10°C to 70°C with derating
2% peak-to-peak
Yes, it is DC input capable.
2 kV
Efficiency typically ranges from 73% to 83%.
