| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,225 pcs
|
1225 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Connector Type | |
| Contact Finish | |
| Contact Material | |
| Features | |
| Height Above Board | |
| LED Color | |
| Lead Style | |
| Mounting Type | |
| Number of Cores per Jack | |
| Number of Ports | |
| Number of Rows | |
| Operating Temperature | |
| Orientation | |
| Shielding | |
| Tab Direction | |
| Termination | |
| Termination Style |
The Bel Fuse S811-1X1T-06-F is a single-port RJ45 modular jack with integrated magnetics designed for 10/100 Base-T Ethernet applications. It supports AutoMDIX for automatic crossover detection. The connector is oriented at a 90° angle (right) with the tab facing down, making it suitable for edge-mount designs.
This jack is shielded with an EMI finger to reduce electromagnetic interference. It includes board guide and solder retention features for reliable surface mount assembly. The contacts are made of copper alloy with a gold finish, ensuring corrosion resistance and consistent electrical performance. The height above the board is 0.502 inches (12.75 mm).
The S811-1X1T-06-F operates over a temperature range of 0°C to 70°C. It does not contain an LED indicator. The connector is terminated via solder and is RoHS compliant (unverified). Applications include 10/100 Base-T networking equipment, switches, routers, and industrial Ethernet devices.
| Qty | Low | High |
|---|---|---|
| 1+ | $5.28 | $5.28 |
| 10+ | $4.49 | $4.49 |
| 25+ | $4.21 | $4.21 |
| 50+ | $4.01 | $4.01 |
| 175+ | $3.67 | $3.67 |
| 350+ | $3.49 | $3.49 |
| 525+ | $3.39 | $3.39 |
| 875+ | $3.27 | $3.27 |
| 1,225+ | $3.20 | $3.20 |
| 1,750+ | $3.12 | $3.12 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
1 port.
Surface mount.
90° angle (right) with tab down.
Yes, shielded with EMI finger.
Gold.
0°C to 70°C.
10/100 Base-T and AutoMDIX.
