S8101-46R SMT cable clip for coax grounding, C-Type elongated split design. Solder mount, phosphor bronze with tin plating, accommodates up to 2 x Ø1.0mm cables.
Mfr Part #:

S8101-46R

Available from 1 distributors
Mfr Name: Harwin Inc.
Harwin Inc.
SMT cable clip for coax grounding, C-Type elongated split design. Solder mount, phosphor bronze with tin plating, accommodates up to 2 x Ø1.0mm cables.
✓ Total Stock: 100 pcs
$ Price Range: $0.14 - $0.29

S8101-46R Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Speed Components Ltd ✓
Non-Authorised Inventory information
100 pcs
On Request
100 pcs On Request 1 On Request On Request 17+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

S8101-46R Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Features
Height
Length
Material
Material Thickness
Mounting Type
Type
Type Attributes
Width
View Similar Products (0)

S8101-46R Description

Short technical summary and product information.

The S8101-46R is a surface mount cable clip designed for coax grounding applications. It features a C-Type elongated split clip body made from phosphor bronze with a tin plated finish, providing corrosion resistance. The clip measures 5.00mm in length, 4.00mm in width, and 1.50mm in height, with a material thickness of 0.20mm.



This clip is compatible with RG178, RG179, and RG316 coaxial cables and can accommodate up to two cables with a maximum diameter of 1.0mm. It is designed for solder mounting and is packaged in tape and reel format on a 330mm reel with a standard quantity of 3000 pieces per reel.



The clip is suitable for automated pick-and-place assembly and can be soldered during the same reflow process as other board components, reducing assembly time compared to plastic clip alternatives.

S8101-46R Quick Information

Product Type: Cable Clip
Series: S8101
Canonical Name: SMT Cable Clip, Coax Grounding Clip, up to 2 x Ø1.0mm cables
Subcategory: Coax Grounding Clip

S8101-46R Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 (Unlimited)
REACH Status: REACH Unaffected

S8101-46R Estimated Pricing

Qty Low High
1+ $0.29 $0.29
10+ $0.24 $0.24
25+ $0.23 $0.23
50+ $0.22 $0.22
100+ $0.21 $0.21
250+ $0.19 $0.19
500+ $0.18 $0.18
1,000+ $0.18 $0.18
3,000+ $0.16 $0.16
6,000+ $0.15 $0.15
9,000+ $0.15 $0.15
15,000+ $0.14 $0.14
21,000+ $0.14 $0.14
30,000+ $0.14 $0.14

Estimated market price range - modelled values for guidance only, not live distributor offers.

S8101-46R Features

  • SMT coax grounding cable clip.
  • Phosphor bronze with tin plating.
  • Accommodates up to 2 x Ø1.0mm cables.
  • Compatible with RG178, RG179, RG316 coax.
  • Tape and reel packaging for automated placement.

S8101-46R Applications

  • Grounding coaxial cable braids in RF assemblies.
  • Cable management in compact SMT designs.
  • Automated pick-and-place PCB assembly.

S8101-46R FAQs

5 frequently asked questions generated from this part’s specifications.
What is the maximum cable diameter this clip can accommodate?

The clip accommodates up to 2 cables with a maximum diameter of 1.0 mm each.

Which coaxial cables are compatible with the S8101-46R?

The clip is compatible with RG178, RG179, and RG316 coaxial cables.

What is the mounting method for this cable clip?

The clip is designed for solder mounting.

What material is the S8101-46R made from?

The clip is made from phosphor bronze with a tin plated finish.

Is the S8101-46R RoHS compliant?

The part is listed as RoHS3 Compliant, but this status is unverified.
