S2M The TSC S2M is a high-precision S-type load cell designed for tensile and compressive force measurements. It offers an accuracy class of 0.02% and a measuring range from 10 N to 1 kN.

Mfr Part #:

S2M

Mfr Name: TSC

The TSC S2M is a high-precision S-type load cell designed for tensile and compressive force measurements. It offers an accuracy class of 0.02% and a measuring range from 10 N to 1 kN.

✓ Total Stock: 3,000 pcs

$ Price Range: $0.99

S2M Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Partservice ✓ Non-Authorised Inventory information	3,000 pcs On Request	3000 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

S2M Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	TSC
Cable Type	Drag-chain-compatible PU cable
Output Signal	2 mV/V
Overload Protection	1000 % of nominal force

View Similar Products (0)

S2M Description

Short technical summary and product information.

The S2M S-type load cell from TSC is a highly accurate and economical force transducer suitable for a wide range of static and dynamic measurement applications. It is particularly well-suited for measuring smaller forces, with the lowest nominal measuring range starting at 10 N and extending up to 1 kN.

This load cell boasts an HBM accuracy class of 0.02%, ensuring precise measurements with minimal non-linearity, reversibility error, and lateral force effect. The consistently high output signal of 2 mV/V guarantees a good signal-to-noise ratio, even at lower nominal forces. Integrated overload protection safeguards the S2M against extreme overloads, enhancing its durability and reliability in demanding environments.

The S2M features a drag-chain-compatible PU cable that is resistant to many oils and chemicals, making it flexible and rugged. It is designed for immediate use with common cable lengths and ready-assembled connectors available for HBM measuring amplifiers. TEDS electronic data sheets, knuckle eyes, and calibration services are also available options for quick setup and integration into data acquisition systems.

S2M Quick Information

Product Type: Load Cell

Canonical Name: S2M S-Type Load Cell

Subcategory: S-Type

S2M Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

S2M Estimated Pricing

Qty	Low	High
1+	$0.99	$0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

S2M Features

High-precision S-type load cell.
Measures tensile and compressive forces.
Accuracy class of 0.02%.
Nominal force range 10 N to 1 kN.
Integrated overload protection.

S2M Applications

Suitable for static and dynamic measurements.
Ideal for applications with smaller forces.
Use in industrial automation systems.
Integration with HBM data acquisition.

S2M FAQs

5 frequently asked questions generated from this part’s specifications.

What is the accuracy class of the TSC S2M load cell?

The HBM accuracy class of the S2M load cell is 0.02%.

What is the measuring range of the S2M load cell?

The nominal force measuring range for the S2M load cell is from 10 N to 1 kN.

What is the output signal of the S2M load cell?

The S2M load cell provides a high output signal of 2 mV/V.

How is the S2M load cell protected against overload?

The S2M load cell features integrated overload protection with a force limit of 1000% of the nominal force.

What type of cable is used with the S2M load cell?

The S2M load cell is equipped with a drag-chain-compatible PU cable that is resistant to many oils and chemicals.
