The TDK Corporation RWS50B-48 is an enclosed AC/DC converter designed for ITE (Commercial) applications. It delivers 50W of power with a 1.1A current output and a 48V nominal output voltage.
Key electrical specifications include an efficiency of 88% and an isolation voltage of 3 kV. The converter supports adjustable output, DC input capability, and universal input voltage ranges. It operates within a temperature range of -20°C to 70°C with derating.
Mechanically, this unit is designed for chassis mounting and has dimensions of 81.5mm in length, 82.0mm in width, and 34.0mm in height. It features a single output and is RoHS3 compliant.
This converter is suitable for various commercial applications requiring a reliable power supply solution.
The RWS50B-48 provides a single 48V output at 1.1A.
The power rating is 50W.
The operating temperature range is -20°C to 70°C with derating.
The efficiency is 88%.
The isolation voltage is 3kV.
The RWS50B-48 uses chassis mount.
