| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Storage Temperature | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The TDK Corporation RWS15A-5/A is an enclosed AC/DC converter from the RWS series, delivering 15W of power with a 5V output voltage and a maximum current of 3A. This unit is designed for industrial applications, offering a universal input voltage range of 85-265 VAC.
Key electrical specifications include a typical efficiency of 72%, line regulation of 20mV, and load regulation of 40mV. It also features overcurrent protection set at >105% and overvoltage protection within the 5.75-6.75V range. The converter operates within a temperature range of 0°C to 60°C with derating.
Designed for easy integration, the RWS15A-5/A utilizes a chassis mount type and screw terminal connections. Its dimensions are 35 x 97 x 98.5 mm, with a weight of 270g. The unit comes with a 5-year warranty, highlighting its reliability for industrial environments.
The output voltage is 5 VDC.
The maximum output current is 3 A.
The input voltage range is 85-265 VAC.
The operating temperature range is 0°C to 60°C, with derating.
Yes, it is RoHS3 Compliant.
