RWS150B-12/CO2 The TDK Corporation RWS150B-12/CO2 is a 150W AC/DC converter with a 12V output. It features adjustable output and chassis mounting.
Mfr Part #:

RWS150B-12/CO2

Mfr Name: TDK Corporation
TDK Corporation
The TDK Corporation RWS150B-12/CO2 is a 150W AC/DC converter with a 12V output. It features adjustable output and chassis mounting.
Stock on Request

RWS150B-12/CO2 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Approval Agency
Current
Efficiency
Features
Mounting Type
Number of Outputs
Operating Temperature
Power (Watts)
Type
Voltage

RWS150B-12/CO2 Description

Short technical summary and product information.

The TDK Corporation RWS150B-12/CO2 is an enclosed, conformal coated AC/DC converter designed for ITE (Commercial) applications. It delivers 150W of power with an output voltage of 12V and a current rating of 13A.



Key electrical specifications include an efficiency of 87% and an isolation voltage of 3 kV. The converter supports adjustable output, DC input capability, and universal input. It operates within a temperature range of -20°C to 70°C, with derating.



Mechanically, this unit is designed for chassis mounting and has dimensions of 128.0mm x 94.0mm x 41.0mm. It has received CE approval.



Compliance information indicates RoHS3 compliance, REACH unaffected status, and an MSL of 1.

RWS150B-12/CO2 Quick Information

Product Type: AC DC Converter
Series: RWS150B
Canonical Name: TDK Corporation RWS150B-12/CO2 AC/DC Converter

RWS150B-12/CO2 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

RWS150B-12/CO2 Features

  • 150W AC/DC converter with 12V output.
  • 13A output current capability.
  • Chassis mountable enclosed design.
  • Adjustable output and universal input.
  • RoHS3 compliant.

RWS150B-12/CO2 Applications

  • Powers commercial ITE equipment reliably.
  • Adjustable output for flexible voltage needs.
  • Universal input enables global deployment.
  • DC input capable for backup systems.

RWS150B-12/CO2 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the power output of the RWS150B-12/CO2?

The RWS150B-12/CO2 has a power output of 150W.

What is the output current for the RWS150B-12/CO2?

The output current is 13 A.

What type of mounting does the RWS150B-12/CO2 use?

The RWS150B-12/CO2 uses chassis mount.

What is the operating temperature range?

The operating temperature range is -20°C to 70°C (With Derating).

Is the RWS150B-12/CO2 RoHS compliant?

Yes, it is RoHS3 Compliant.
