| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
820 pcs
|
820 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Industrial Grade | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Regulators | |
| Operating Temperature | |
| Output Configuration | |
| Output Type | |
| PSRR | |
| Protection Features | |
| Voltage Dropout (Max) |
The RICHTEK RT9022PE is a positive fixed output linear voltage regulator IC designed for power management applications. It offers a stable 8.3V output voltage and can deliver up to 150mA of current. The device features a low input voltage maximum of 28V and a dropout voltage of 0.95V at 100mA.
With a quiescent current of 115 µA and a PSRR of 50dB at 1kHz, the RT9022PE is suitable for various electronic circuits. It includes overcurrent and overtemperature protection features for enhanced reliability. The operating temperature range is from -40°C to 85°C.
This component is supplied in a TO-252-3, DPAK (2 Leads + Tab), SC-63 package, designed for surface mounting. The RoHS status is reported as ROHS3 Compliant, and REACH status is REACH Unaffected. The Moisture Sensitivity Level (MSL) is 1 (Unlimited).
| Qty | Low | High |
|---|---|---|
| 1+ | $7.19 | $7.19 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is a fixed 8.3V.
The maximum output current is 150mA.
The maximum input voltage is 28V.
The dropout voltage is 0.95V at 100mA.
The quiescent current is 115 µA.
It includes overcurrent and overtemperature protection.
The operating temperature range is -40°C to 85°C.
