| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Overload Protection | |
| Power (Watts) | |
| SVHC Present | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Voltage Range | |
| Width |
The Mean Well RT-65D is a 65-watt triple output AC/DC power supply designed for OEM equipment used in international markets. It features a universal full-range AC input (88-264VAC) and provides three distinct DC outputs: 5V on CH1, 24V on CH2, and 12V on CH3. The total power output is rated at 68W, with specific current ratings for each channel.
This enclosed power supply is designed for chassis mounting and operates via free air convection, eliminating the need for cooling fans. It offers adjustable output voltage ranges for fine-tuning and includes overload and over-voltage protection mechanisms. The unit is built to withstand a 300VAC input surge for 3 seconds and has passed 5G vibration testing.
Key electrical specifications include an efficiency of 79% typical, a hold-up time of 14ms at full load (115VAC), and an inrush current of 40A at 230VAC. The operating temperature range is -25°C to 70°C with derating, and it operates within a humidity range of 20-90% RH non-condensing.
Safety and EMC compliance are met with approvals including UL60950-1, TUV EN60950-1, EN55022 Class B, and EN61000-3-2,-3 standards. The dimensions are 129mm x 98mm x 38mm.
The Mean Well RT-65D provides three outputs: 5V on CH1, 24V on CH2, and 12V on CH3.
The RT-65D has a total power output of 68W.
The RT-65D accepts a universal input voltage range of 88-264VAC.
The typical efficiency of the RT-65D is 79%.
The RT-65D operates within a temperature range of -25°C to 70°C.
The dimensions of the RT-65D are 129.0mm x 98.0mm x 38.0mm.
