| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5,050 pcs
|
5050 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Operating Temperature Range | |
| Package / Case | |
| Slew Rate | |
| Tape & Reel |
The Runic Technology RS821XF is a high-performance CMOS operational amplifier designed for low-voltage applications. It offers a significant gain bandwidth of 14MHz and features Rail-to-Rail input and output stages, allowing for maximum dynamic range.
This operational amplifier is specified for operation across a wide temperature range of -40°C to +125°C. It supports a supply voltage range from +2.5V to +5.5V, making it versatile for various power configurations. The typical input offset voltage is a low 0.6mV, and the input voltage range extends from -0.1V to +5.6V when operating at a 5.5V supply.
The RS821XF is housed in a compact SOT23-5 package, suitable for space-constrained designs. Its excellent speed-to-power consumption ratio and rail-to-rail performance make it an ideal choice for sensor interfaces, active filters, and portable applications.
The typical gain bandwidth is 14 MHz.
The supply voltage range is +2.5V to +5.5V.
The operating temperature range is -40°C to +125°C.
The RS821XF is available in a SOT23-5 package.
The typical slew rate is 10 V/us.
The typical input offset voltage is 0.6 mV.
