| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
40 pcs
|
40 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Configuration | |
| Current | |
| Filter Type | |
| Frequency | |
| Inductance | |
| Mounting Type | |
| Operating Temperature | |
| Self Resonant Frequency | |
| Tape & Reel | |
| Termination Style | |
| Voltage |
The Schaffner RS514-2-02 is a common mode choke filter from the RS series, designed for general-purpose differential/symmetrical mode filtering. It operates with a rated current of 2 A and offers a rated inductance of 120µH.
This component is suitable for applications operating at frequencies from DC to 400 Hz and has an operating voltage rating of 250 VAC. The choke is designed for through-hole mounting and features radial termination.
Key specifications include a maximum DC resistance of 50 mOhms and a self-resonant frequency of 16 MHz. The operating temperature range is -40°C to 125°C. The product is compliant with RoHS3 standards.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The rated current is 2 A at the rated ambient temperature.
The rated inductance is 120µH.
The operating voltage is 250 VAC.
The operating temperature range is -40°C to 125°C.
Yes, the RoHS status is RoHS3 Compliant.
