Mfr Part #:

RS3005

Mfr Name: Kuhnke

The RS3005 is a low power, high voltage CMOS LDO regulator from KUHNKE. It provides a nominal output current of 150mA and can operate from 2.5V to 36V input.

✓ Total Stock: 5 pcs

$ Price Range: $2.16

RS3005 Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
ACK ELEKTRONIK ✓ Non-Authorised Inventory information	5 pcs On Request	5 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

RS3005 Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	Kuhnke
Mounting Type	Surface Mount
Operating Temperature	-40°C to +85°C
Output Voltage	3V

View Similar Products (0)

RS3005 Description

Short technical summary and product information.

The KUHNKE RS3005 series comprises low power, high voltage linear regulators manufactured using CMOS technology. These regulators are designed to operate within an input voltage range of 2.5V to 36V, providing a stable output current of 150mA.

The RS3005 series offers several fixed output voltage options, including 3.0V, 3.3V, 3.6V, 4.36V, 5.0V, 9.0V, and 12.0V, with an output voltage accuracy of ±2.5%. Key features include a low dropout voltage, low quiescent current (11µA typical at light loads), and a low temperature coefficient.

These regulators are available in various surface-mount packages such as SOT23-3, SOT23, SOT23-5, SOT89-3L, and TO-92. They are suitable for applications including audio/video equipment, communication devices, battery-powered systems, and automotive head units. The operating temperature range is -40°C to +85°C.

Applications for the RS3005 include battery-powered equipment, portable electronics, and automotive systems where low power consumption and high input voltage capability are required.

RS3005 Quick Information

Product Type: Linear Regulator

Series: RS3005

Canonical Name: RS3005 Linear Regulator

Subcategory: Special Purpose Transistors

RS3005 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

RS3005 Estimated Pricing

Qty	Low	High
1+	$2.16	$2.16

Estimated market price range - modelled values for guidance only, not live distributor offers.

RS3005 Features

Low power, high voltage CMOS LDO regulator.
150mA nominal output current.
Wide input voltage range up to 36V.
Low quiescent current of 11µA typical.
Available in SOT23, SOT89, and TO-92 packages.

RS3005 Applications

Suitable for battery-powered equipment.
Used in audio and video devices.
Applicable for communication equipment.
Designed for automotive head units.
Ideal for portable electronics.

RS3005 FAQs

5 frequently asked questions generated from this part’s specifications.

What is the nominal output current of the RS3005?

The nominal output current is 150mA.

What is the maximum input voltage for the RS3005?

The maximum input voltage is 36V.

What are the available fixed output voltages for the RS3005?

Available fixed output voltages include 3.0V, 3.3V, 3.6V, 4.36V, 5.0V, 9.0V, and 12.0V.

What is the operating temperature range of the RS3005?

The operating temperature range is -40°C to +85°C.

What packages are available for the RS3005?

The RS3005 is available in SOT23-3, SOT23, SOT23-5, SOT89-3L, and TO-92 packages.
