| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3 pcs
|
3 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Current | |
| Coil Resistance | |
| Coil Type | |
| Coil Voltage | |
| Contact Form | |
| Contact Material | |
| Contact Rating (Current) | |
| Mounting Type | |
| Must Operate Voltage | |
| Operate Time | |
| Operating Temperature | |
| Relay Type | |
| Switching Voltage | |
| Tape & Reel | |
| Termination Style |
The Idec RR2KP-UDC24V is a self-maintained latch relay from the RR2KP series, featuring a DPDT contact form with a 10A contact capacity. This relay utilizes a permanent magnet mechanism for its self-holding function, making it suitable for memory and flip-flop circuit applications. It operates with a 24VDC coil voltage and has a coil current of 60 mA.
The relay offers a switching voltage of up to 240VAC and 30VDC. Its contact material is silver, and it has an operate time of 25 ms maximum. The operating temperature range is -5°C to +40°C. The RR2KP-UDC24V is designed for socketable mounting and features an 11-pin octal termination style.
This latch relay provides enhanced self-holding functions, along with vibration and shock resistance. The self-holding mechanism is not subject to wear, unlike mechanical latch relays. It is recognized by UL and certified by CSA.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Idec RR2KP-UDC24V relay has a contact rating of 10A.
The coil voltage for the RR2KP-UDC24V relay is 24VDC.
The operating temperature range for this relay is -5°C to +40°C.
The RR2KP-UDC24V relay has a DPDT (2 Form C) contact form.
The switching voltage for the Idec RR2KP-UDC24V is 240VAC and 30VDC maximum.
The operate time of the RR2KP-UDC24V relay is 25 ms maximum at the rated voltage.
The Idec RR2KP-UDC24V relay features socketable mounting.
