| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
14 pcs
|
14 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Isolation Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Mean Well USA RPS-300-24-C is a 200W enclosed AC/DC converter designed for medical applications. It delivers a single 24V output at 8.33A with a high efficiency of 92.5%. The converter accepts a universal input range of 90-264 VAC and features adjustable output, remote sense, and standby output. It is chassis mountable with dimensions of 129.8 x 86.1 x 42.9 mm. The unit is approved by CB, CE, cURus, and TUV, and complies with medical safety standards. It operates over a temperature range of -30°C to 70°C with derating, and has a low no-load power consumption of less than 0.5W. The isolation voltage is 4 kV, and leakage current is less than 150 μA. For forced air cooling, the power rating increases to 300W.
-30°C to 70°C with derating.
RoHS3 Compliant (unverified).
90-264 VAC.
24V at 8.33A.
92.5%.
CB, CE, cURus, TUV.
4 kV.
