| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
44,000 pcs
|
44000 pcs | On Request | 1 | On Request | On Request | 20+ | On Request | On Request | |
|
4,000 pcs
|
4000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Height | |
| Inductance | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Ratings | |
| Shielding | |
| Tolerance | |
| Type | |
| Width |
This TDK Corporation RLF7030T-6R8M2R8-T is a fixed inductor designed for surface mounting. It offers a nominal inductance of 6.8 µH with a tolerance of ±20% and a current rating of 2.8 A. The DC resistance (DCR) is a maximum of 44.76 mOhm.
Constructed with a ferrite core and wirewound type, this inductor is shielded, providing protection against electromagnetic interference. It operates within a temperature range of -40°C to 125°C and meets AEC-Q200 automotive qualification standards. The component has dimensions of 7.30mm in length, 6.80mm in width, and 3.20mm in height.
This part is suitable for applications requiring stable inductance and current handling in a compact surface mount form factor, adhering to automotive-grade specifications.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.52 | $0.52 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance value is 6.8 microhenries.
The maximum current rating is 2.8 amperes.
The DC resistance is 44.76 milliohms.
The operating temperature range is -40°C to 125°C.
The material is ferrite.
Yes, it is shielded.
