RK3326 The Rockchip RK3326 is a System On Chip (SoC) with a Quad-Core ARM Cortex-A35 processor and Mali-G31 GPU. It supports 1080P video decoding and encoding.
Mfr Part #:

RK3326

Available from 2 distributors
Mfr Name: Rockchip
Rockchip
The Rockchip RK3326 is a System On Chip (SoC) with a Quad-Core ARM Cortex-A35 processor and Mali-G31 GPU. It supports 1080P video decoding and encoding.
✓ Total Stock: 1,492 pcs

RK3326 Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Xingangxin ✓
Non-Authorised Inventory information
1,300 pcs
On Request
1300 pcs On Request 1 On Request On Request On Request On Request On Request
PROSOFT ELECTRONICS ✓
Non-Authorised Inventory information
192 pcs
On Request
192 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

RK3326 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Memory Type
SVHC Present
View Similar Products (0)

RK3326 Description

Short technical summary and product information.

The Rockchip RK3326 is a versatile System On Chip (SoC) designed for embedded applications. It features a Quad-Core ARM Cortex-A35 CPU operating at up to 1.5GHz, paired with a Mali-G31 GPU that supports OpenGL ES3.2 and Vulkan 1.0.



This SoC excels in multimedia processing, offering multi-format 1080P 60fps video decoding capabilities for codecs like H.265 and H.264, as well as 1080P video encoding for H.264 and VP8. The display interface supports RGB, LVDS, and MIPI-DSI with resolutions up to 1920x1080.



Memory support includes 32-bit DDR4, DDR3, DDR3L, LPDDR3, and LPDDR2, along with interfaces for MLC NAND, eMMC 4.51, and Serial Nor FLASH. Connectivity options are extensive, featuring MIPI CSI and DVP sensor interfaces with an integrated 8M ISP, multiple audio interfaces (I2S/TDM, PDM, I2S/PCM), SDIO3.0, USB2.0 OTG, I2C, UART, and SPI.



The RK3326 is suitable for a range of applications requiring robust processing and multimedia capabilities within a compact form factor.

RK3326 Quick Information

Product Type: System On Chip (SoC)
Series: RK33 Series
Canonical Name: RK3326 System On Chip (SoC)
Subcategory: SoC

RK3326 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

RK3326 Features

  • Quad-core ARM Cortex-A35 CPU up to 1.5GHz.
  • Mali-G31 GPU with OpenGL ES3.2 support.
  • 1080P 60fps multi-format video decoding.
  • 1080P H.264/VP8 video encoding.
  • Wide range of memory and connectivity options.

RK3326 Applications

  • Embedded systems requiring multimedia processing.
  • Devices needing 1080P video playback.
  • Applications with camera sensor integration.
  • IoT devices with robust connectivity needs.

RK3326 FAQs

7 frequently asked questions generated from this part’s specifications.
What CPU architecture does the RK3326 use?

The RK3326 uses a Quad-Core ARM Cortex-A35 CPU.

What is the maximum clock speed of the RK3326 CPU?

The CPU in the RK3326 can operate at speeds up to 1.5GHz.

Which GPU is integrated into the RK3326?

The RK3326 integrates a Mali-G31 GPU.

What video decoding formats does the RK3326 support?

The RK3326 supports multi-format 1080P 60fps video decoding including H.265, H.264, VC-1, MPEG-1/2/4, and VP8.

What display resolutions can the RK3326 support?

The RK3326 supports display resolutions up to 1920x1080.

What types of memory does the RK3326 support?

The RK3326 supports 32-bit DDR4-1600, DDR3-1600, DDR3L-1600, LPDDR3-1600, and LPDDR2-1066 memory.

What storage interfaces are available on the RK3326?

The RK3326 supports MLC NAND, eMMC 4.51, and Serial Nor FLASH.
