RF2360TR7 The RFMD RF2360TR7 is a GaAs MESFET RF amplifier designed for CATV applications. It offers a gain of 20dB and a noise figure of 1.1dB.
Mfr Part #:

RF2360TR7

Available from 2 distributors
Mfr Name: RFMD
RFMD
The RFMD RF2360TR7 is a GaAs MESFET RF amplifier designed for CATV applications. It offers a gain of 20dB and a noise figure of 1.1dB.
✓ Total Stock: 2,845 pcs

RF2360TR7 Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Optech Co.,Limited ✓
Non-Authorised Inventory information
2,500 pcs
On Request
2500 pcs On Request 1 On Request On Request 1009/ On Request On Request
Smaxon Electronics ✓
Non-Authorised Inventory information
345 pcs
On Request
345 pcs On Request 1 On Request On Request 02+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

RF2360TR7 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Approval Agency
Gain
Lead Style
Noise Figure
Package / Case
RF Type
Supply Current
Supply Voltage
Tape & Reel
Test Frequency
View Similar Products (0)

RF2360TR7 Description

Short technical summary and product information.

The RFMD RF2360TR7 is a Gallium Arsenide (GaAs) MESFET amplifier designed for RF, IF, and RFID applications, specifically for CATV systems. This component operates within a frequency range of 5 MHz to 1.5 GHz, providing a typical gain of 20dB.



Key electrical characteristics include a noise figure of 1.1dB and a P1dB compression point of 25.1dBm. The device requires a supply voltage between 6V and 9V, drawing a current of 100mA to 109mA. It is suitable for ISM and Broadcast Television applications.



The RF2360TR7 comes in a 16-SOIC package with tape and reel packaging. The package dimensions are 0.154 inches (3.90mm) wide and it features 14 leads with fused leads.



This amplifier is designed for applications requiring high performance in RF signal amplification within the specified frequency bands.

RF2360TR7 Quick Information

Product Type: RF Amplifier
Canonical Name: RFMD RF2360TR7 GaAs MESFET CATV Amplifier
Subcategory: GaAs MESFET

RF2360TR7 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

RF2360TR7 Features

  • GaAs MESFET RF amplifier for CATV.
  • Wide frequency range from 5 MHz to 1.5 GHz.
  • Typical gain of 20dB.
  • Low noise figure of 1.1dB.
  • 16-SOIC package on tape and reel.

RF2360TR7 Applications

  • Suitable for CATV systems.
  • Used in ISM band applications.
  • Ideal for broadcast television.
  • RF signal amplification needs.

RF2360TR7 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the typical gain of the RF2360TR7?

20 dB.

What is the noise figure?

1.1 dB.

What frequency range does it cover?

5 MHz to 1.5 GHz.

What is the supply voltage range?

6 V to 9 V.

What is the supply current?

100 mA to 109 mA.

What is the P1dB compression point?

25.1 dBm (323.6 mW).

What package is the RF2360TR7 available in?

16-SOIC (0.154", 3.90mm Width) 14 Leads, Fused Leads.
