The E-T-A REX12-TA2-107-DC24V-6A/6A is a 2-pole solid state electronic circuit protector designed for selective overcurrent protection. It offers a current rating of 6A and a voltage rating of 30VDC, with a push-to-reset actuator for manual ON/OFF/reset functionality.
This circuit breaker is part of the REX12 series, featuring a compact design with a width of 6.25 mm per channel. It is suitable for switching capacitive loads up to 20,000µF and provides clear status indication via LED and signal contact. The protector meets requirements for cable protection to EN60204-1 and holds UL508 listed approval and NEC Class2 compliance.
Mounting is achieved via a holder, and connection is made using push-in terminals for tool-free wiring. The REX12-T offers selective protection by responding faster to short circuits or overloads than the switch mode power supply. It is available in fixed and adjustable current ratings from 1A to 10A.
The current rating is 6 A.
The voltage rating is 30 VDC.
It is a solid state circuit breaker.
It has 2 poles.
It uses a push to reset actuator.
The mounting type is holder.
It can switch capacitive loads up to 20,000 µF.
