The Recom Power REDIM07 is a versatile dimming module engineered for use with LED drivers, energy-saving lamps, dimmable LED lamps, and low-voltage halogen lamps. It reliably operates with base loads starting from 7W, providing a smooth dimming curve down to zero.
Key features include an input voltage range of 198-264 VAC and an output power capacity of 7-110 W/VA. The module is equipped with over-temperature protection, activating at 115°C, and includes a replaceable slow-blow input fuse. It operates within an ambient temperature range of -20°C to +80°C, with a maximum case temperature of +80°C.
The REDIM07 is housed in a compact plastic case measuring 71.0 x 71.0 x 35mm and weighs 70g. Connections are made via screw terminals suitable for wire diameters of 1.5-2.5mm². The dimmer is compliant with EN60669-1 and EN60669-2-1 standards, ensuring safety for household installations. It comes with a 5-year warranty, highlighting its durability and reliability.
This dimming module is ideal for creating customized lighting solutions where precise control over light levels is required. Its robust design and broad compatibility make it a suitable choice for various lighting applications.
198-264 VAC.
7-110 W/VA.
-20°C to +80°C.
71.0 x 71.0 x 35mm.
Yes, it is compliant with EN60669-1 and EN60669-2-1.
5 years.
10 pieces per package.
